Multy Fuction Snap-in & Surface mount Type


SM008/016 Series
  Rating : 50mA 12V DC
  Contact Resistance : 1Ω max.

Features
  A push on switch with a clear-click operational feel
  An encoder with detents and excellent
  operational feel
  4-directions & center push type.

Applications
  Scroll of Menu and input for Audio Visual Equipment
  Level controls for car audio & navigation system
  Portable audio devices, Personal digital assistant.


Main specifications
  Encoder SM016GJ50
Encoder Push on Encoder Push on
Detent(pulse) /Travel 8 detent(4pulse) Center : 0.15mm 16 detent(8pulse) Center : 0.15mm
4-direction : 5˚±3˚ 4-direction : 5˚±3˚
Operating Force 150gf Center : 500gf 150gf Center : 500gf
4-direction : 400gf 4-direction : 400gf
Rating 2mN·m
Contact Resistance 15,000 Cycles20,000 Cycles
Operating Life 30,000 Cycles
